Products

Fencing

Pine Products offer the full range of fence materials including rough sawn and dressed palings and posts, rails, capping and kick boards. Our timber fence products are treated to ensure durability while out in the New Zealand elements.

Paling Options

Post Options

Rail Options

Capping Options

Kick Board Options

Timber Lingo

Description	Size (mm)	Treatment / Grade	Length	Pack Size	Notes
PALING	150x12	H3.2 R/S	1.2m / 1.5m / 1.8m / 2.1m	420 pcs
PALING	150x19	H3.2 R/S	1.2m / 1.5m / 1.8m / 2.1m	252 pcs
PALING	68x19	H3.2 D4S	1.2m / 1.5m / 1.8m / 2.1m	300 pcs
PALING	90x19	H3.2 D4S	1.2m / 1.5m / 1.8m / 2.1m	200 pcs
PALING	140x19	H3.2 D4S	1.2m / 1.5m / 1.8m / 2.1m	210 pcs

Description	Size (mm)	Treatment / Grade	Length	Pack Size	Notes
POST	100x100	H4 R/S WAT	2.4m / 2.7m / 3m / 4.8m / custom	40 pcs
POST	100x75	H4 R/S WAT	2.4m / 2.7m / 3m / 4.8m / custom	50 pcs
POST	125x75	H4 R/S WAT	2.4m / 2.7m / 3m / 4.8m / custom	40 pcs
POST	90x90	H4 KD RHD	1.8m / 2.7m / 3m / 3.6m / 4.8m / custom	32 pcs	F7C Kiln-Dried after treatment
POST	88x88	H4 KD RHD	1.8m / 2.4m / 3m / 3.6m / custom	32 pcs	SG8 Kiln-Dried after treatment

Description	Size (mm)	Treatment / Grade	Length	Pack Size	Notes
STD RAIL	75x50	H3.2 R/S	4.8m / 5.4m / 6m	104 pcs
STD RAIL	100x50	H3.2 R/S	4.8m / 5.4m / 6m	80 pcs
STD RAIL	150x50	H3.2 R/S	4.8m / 5.4m / 6m	56 pcs
STD RAIL	200x50	H3.2 R/S	4.8m / 5.4m / 6m	40 pcs
No.1 RAIL	75x50	H3.2 R/S	4.8m / 5.4m / 6m	104 pcs	Special Order
No.1 RAIL	100x50	H3.2 R/S	4.8m / 5.4m / 6m	80 pcs	Special Order
No.1 RAIL	150x50	H3.2 R/S	4.8m / 5.4m / 6m	56 pcs	Special Order

Description	Size (mm)	Treatment / Grade	Length	Pack Size	Notes
CAPPING	90x45	H3.2 P/G	4.8m	80 pcs
CAPPING	140x45	H3.2 P/G	4.8m	56 pcs

Description	Size (mm)	Treatment / Grade	Length	Pack Size	Notes
190x18	H3.2 P/G	H3.2 P/G	4.8m / custom	75 pcs

GRADING GUIDELINES FOR RADIATA PINE

No.1 Clear Grade

Clear on all four faces with the occasional minor blemish permissible as per N.Z. Timber Grading Rules NZS 3631:1988. Typical end uses include mouldings, dressed boards, panelling, and products that require a stained finish.

Prem Grade

A near clear grade used in decking which allows for a small number of tight defects on the best face and edges. Backface allows occasional large or broken knot defects and some hit and miss dressing.

SG8 Dry

SG8 dry is a structural grade ex pruned log that allows tight and live knot defects. Suitable for Lintels, floor joists, roof beams, general framing, trusses, decking joists, Verandah posts, Pergola and other outdoor applications.

Merchant Grade

Contains the next layer of wood beyond the core of the log. Grading allows heartwood and any number of knots and defects which are generally sound and tight (inter-grown). Grading allows for a small amount of pith (less than 10% of the length), cone hole, needle trace, light to moderate resin, light blue stain and wane on up to 30% of the edge. Cluster and spike knots are allowed as long as structurally sound. Grading does not allow pith (greater than 10% of length), dead knots, decaying timber and broken pieces.

Industrial OR Boxing Grade

Contains the core (pith) of the log and surrounding heavy heartwood zone. Grading allows any amount of pith, spiral grain, large knots, broken knots, spike and cluster knots. Grading allows cone hole, needle trace, resin pockets, moderate blue stain and wane on 50% of edges. Grading does not allow decay, broken and fallen knots bigger than half the width, heavy blue stain, and pieces of timber that do not hold together (are not structurally sound).

H3.1 --- Outside, above ground, periodic wetting but where the timber can dry out; some leaching. Requires painting for ongoing protection.

H3.2 --- Outside above ground, periodic wetting but where the timber can dry out; some leaching

H4 --- In or on the ground subject to severe wetting and leaching

H5 --- In or on the ground subject to severe wetting and leaching, with or in freshwater

WAT --- Wet After Treatment

UT --- Untreated

GS --- Green Sawn

KD --- Kiln Dried

R/S --- Rough Sawn

DAR --- Dressed

D4S --- Dressed four sides

RHD --- Rougher Headed
